Detect particle size

0.5,5.0 μm

Sampling flow

0.1CFM(2.83L/min)

mm ） Overall dimension (L*W*H) mm

160*120(+气 嘴25)*68 160*120(+ air nozzle 25)*68

Weight

1.3kg

Maximum power consumption

20w

Power supply

DC 12V±10%

Sampling pumps

Built - in pump (brand: Thomas )

Detection unit

颗/ ft 3 Pcs /t3

C oncentration error

30%

Repeatability

≤10%

M easurement accuracy

±10%

Self-cleaning time

≤10 min

Output mode

RS 485

Light source and life

半导体激光器，寿命大于30000h Semiconductor laser , life greater than 30000h

Environment

温度：10--30℃ ， 湿度： 20%—75%； 大气压力：86kPa —106kPa Temperature: 10–30 ℃, humidity : 20%—75% ; Atmospheric pressure :86 kPa -106 kPa
